STEP 3

Connect the module, assembled in step 2,
with bracket item 15 to the top bracket
item 3 on the antenna, as shown, using hardware
items 7, 8, 9 and 10.
Do not tighten the nut.

SHEET 4 OF 6

WIRELESS EDGE

RD41425500C/REV-A
