MOCET IP3022 SOHO IP Deskphone User Guide
1.1. Phone Features and Specifications
 Complete VoIP and networking protocol support
 Rich supplementary call services and phone features
 3 SIP Lines with 6 call appearances
 Graphic 128x64 pixels LCD display with backlight
 HD audio chamber design in handset and speakerphone
 3-way on-phone conferencing
 Independent 4 soft keys for easy menu operation
 8 programmable keys
 Support headset port and EHS port for Wireless BT headset
 Built-in two ports 10/100 Ethernet switch with class1 power over Ethernet (PoE)
 Extensive IP networking support including VLAN, VPN, OpenVPN, IPv4 and IPv6
 Auto-provisioning and firmware upgrade
 Web management and LCD configuration
 Asterisk, 3CX, Freeswitch, Metaswitch and Broadsoft interoperability
 Option items: power adapter, wall-mount kit, electronic hook switch (IP-EHS) for
wireless BT headset, and external dial module (IP-EDMX) 
1.2. Requirements
The phone requires the following environments:
 Compatible SIP-based IP PBX system or Internet-based hosted SIP service account
 Ethernet LAN (10/100 Base-T)
1.3. Installation and Setup
The phone can support two different tilt angles of 49° and 30° (see below).
