MOCET IP3092/IP3092L Communicator User Guide
Number Port/Connector Description
1 iPad docking port Apple 30-pin connector or 8-pin lightning
connector on front shell
2 Handset port RJ-9 for attaching handset with curly phone cord
3 Microphone input port To connect optional desktop microphone set
4 Ethernet LAN port To connect the Communicator to the LAN
5 Ethernet PC port To connect a PC to the LAN
6 12VDC Power port 2.5mm port for external power adapter
7 Console port For service use only
8 Kensington lock mount To lock the Communicator to a desk with
Kensington lock
9 Micro SD card reader For voicemail, IVR prompts, and firmware
updates
10 USB 2.0 host port Can be used to charge an iPhone or other
device; also for voicemail, IVR prompts, and
firmware updates
11 MOCET accessory port Reserved for future use
12 Wiring duct Allows curly handset cord to be routed to port
13 Headset port 3.5mm port for Apple or other headset
1.5. Communicator Keys Function Description
The Communicator supports two audio system control modes: iPad app mode and IP
Commander mode,The following section shows how to operate the Communicator in both
modes.
1.5.1. Communicator Key Functions for iPad app mode:
The default configuration of the Communicator automatically enables the audio controls for
FaceTime, Skype, Hookflash, Bria or other iPad apps. In iPad app mode, the
Communicator key functions are as follows:
Name of Key Description
Speakerphone
Press this key to enable or disable the Speakerphone; a blue
LED is used to indicate status
