Freeze-dryer EPSILON 2-6 LSCplus
4 Storage and transport
32
Version 10/2012, Rev. 1.6 of 16/12/2014 • sb
Translation of the original operating manual
4.4 Packaging
The freeze-dryer is packaged in a wooden crate.
• After opening the packaging, take out the accessories.
• Remove the packaging material.
• Remove the side walls of the crate.
• Lift the freeze-dryer upwards with a lifting device. Always reach under
the freeze-dryer from the front side (A).
CAUTION
The freeze-dryer Epsilon 2-6D LSCplus weighs approx. 330 kg!
CAUTION
The centre of gravity of the freeze-dryer is off-centre!
1
Steerable castors
2 Supports for transport
3 Supporting frame
4 Fixed castors
A Front side
Fig. 15: Bottom of the freeze-dryer
• Retain the packaging for any possible future transport of the freeze-
dryer.
