Lingenfelter L460095297 Lingenfelter LNC-002 Launch Controller v2.0 User Manual
Page 2
Parts List
#
Part number
Description
1
LNC-002
LPE Launch Controller
1
72” trigger wire harness (part of PN LNC-002)
2
hook & loop tape, 3.5” length
4
AV16037
self-tapping screw
1
L450080000
Transient voltage suppression (TVS) diode kit
1
L920010000
LPE decal
1
instructions
Optional Items
• 3 bar MAP sensor
12223861
• Additional transient voltage suppression (TVS) diode
L450080000
• TPS and clutch switch
NO-00-6102
• MPH activated switch
L460050000
• LED for indicator light
• Red 12 vdc LED with 30 cm leads
L450030000
• Green 12 vdc LED with 30 cm leads
L450040000
• Sealed 40 amp heavy duty relay kit
L450100000
• Red LED lighted paddle toggle switch, 20 amp
DC-7600500
Specifications:
•
Custom molded high temperature glass filled Nylon 6 enclosure with direct access to the controller
settings without requiring removal of a cover or access panel.
•
40 MHz 16-bit automotive qualified processor with eight channel Enhanced Time Module.
•
Each coil drive circuit has a dedicated timer to keep the timing accurate over the full RPM range.
•
Independent coil drive provides Sequential Ignition Kill when RPM limiting is active.
•
Reverse battery protection.
•
Both of the activation inputs have active clamps and optical isolation to suppress electrical noise
from external solenoids (such as trans brake and line lock).
•
Digital filter provided in software to further isolate electrical noise on the activation inputs.
•
Separate RPM x100, RPM x1000, Degrees and Rate switches for easier setting adjustments.
•
RPM limiter activation point can be adjusted from 1500 to 9,900 RPM in 100 RPM increments.
•
Both Ground Activation and +12 Volt Activation inputs are provided for RPM limit activation.
•
Timing retard capability with up to 15 degrees of timing retard authority.
•
Dedicated timing retard trigger input wire (for nitrous activation or other timing retard activation).
•
GM 3 bar manifold air pressure (MAP) sensor connector for boost based timing retard function.
•
Analog voltage output wire for sending timing retard information to data acquisition systems
(EFILive, HPTuners, DashDAQ, etc.)
•
True plug-and-play coil pack connection design for ease of installation and removal.
•
Fully encapsulated (potted) construction for added durability.
•
90 day warranty (from date of purchase).
Page 1 of 17
