Camaro 160086 xa coilovers – Lingenfelter L500151410 Lingenfelter - Pedders Camaro SS Coil Over Shocks User Manual
Page 2
www.PeddersUSA.com
248.522.8021
Camaro 160086
Xa Coilovers
PRE- INSPECTION
Body and chassis tolerances can be significant. This affects ride heights up to 15mm. On a very level ground and
before raising the vehicle, measure and record the ride heights from the lower wheel lip, thru center of the wheel, to
the upper fender opening. This should be done with an empty trunk and no passengers in the vehicle. Many vehicles
you will find a 5mm variation side to side. This could be caused by strut bushings, OE coil rate variations, and/or the
body tolerances. You may want to consider these variations when setting up the presets on the height adjustments
Making presets are easy to do. To improve accuracy, being fanatic on the presets is recommended and does not take
up a large amount of time. Measuring in millimeters is easier and more accurate. For example, 1mm equals
0.039370079 inches. I hope you see my point!
We also have alternative coils available for those who want different coil rates .
Please note that there are 2 wheel lug nut torques in GM’s SI documentation. One is 100lbft and the other is 140lbft
as of 7/28/09. G8 is 125lbft per GM
