Page 28
98. LPE recommends that the LPE
CTS-V Varimax intercooler pump kit
(PN:L330030709) be used to maximize the
effectiveness of the high capacity intercooler
radiator. Steps 99 to 104 apply when using
this intercooler pump upgrade kit. If you are
using the stock intercooler pump, skip to
step 105.
99. Strip the end of the un-terminated orange
wire.
100. Slide the green weather pack seal over the
wire, and crimp the female terminal onto the
wire.
97. Place the three ground eyelets from the fan
harness over the hole, reinstall the bolt, and
torque to 11 lb-ft (15 Nm).
