11
3.0 Dimensions
81mm
(3.19 ″)
132mm
(5.2 ″)
Alarm Panel
Dimensions
Panel Cutout
Dimensions
3.00
″ x 2.00″
NOT TO SCALE
111mm
(4.37
″)
R1
15V
s
1
IDC
2
3
232
C
29mm
(1.14 ″)
29mm
(1.14 ″)
74mm
(2.91 ″)
48mm
(1.89 ″ ) 19mm
(0.75
″
)
9.75mm
(0.38
″
)
Front
View
Rear
View
Side
View
40.5mm
(1.59 ″)
40.5mm
(1.59 ″)
2 x Fixing Holes
2.5mm dia
for 2 x No. 6
Self tapping screws provided
76.2mm
(3.00 ″)
50.8mm
(2.00 ″)
111mm
(4.37 ″)
