Labconco SteamScrubbe & FlaskScrubbe Glassware Washers 44204 Series - Manual (Page 79)

Labconco Glassware Washer Service/Technical Manual
73
45415-00 Clamp, Blower to mount (FS)
45277-00 Duct Reducer, 3” to 2” (FS)
19686-00 Clamp, Motor Blower to 3”(FS)
16245-01 Hose, 3” (Motor Blower)(FS)
19676-00 Clamp, Reducer to 2” (FS)
16245-00 Hose, 2” from Blower (FS)
45881-00 Relay Board Assy
45880-00 Pump Inlet Elbow
45869-00 Drain Valve, 115V
45869-01 Drain Valve, 230V
45867-00 DI Fill Valve, 115V
45867-01 DI Fill Valve, 230V
45859-00 I/O Sensor Cable
45853-00 Main Wiring Harness
45843-00 Drain Pump 115V
45843-01 Drain Pump 230V
45842-00 Circulation Pump 115V
45842-01 Circulation Pump 230V
45839-00 Pump Mount
45936-00 Pump Outlet Tube (SS)
45824-00 Pump Outlet Tube (FS)
45864-00 Hollow Ball (FS)
45996-00 Tube, Clamp
45819-00 Drain Hose
14888-00 Drain Hose Clamp
45818-00 Drain Pump Inlet Hose
45279-00 DI Pump Assy
44373-00 Blower Adaptor
44115-00 Fill Valve 115V
90816-00 Fill Valve 230V
45932-00 Drain Pump Bracket
18614-00 Ball Bearing Pulley (door)
19113-16 Washer (4)
18810-16 CapScrew
19373-21 HexNut
16239-00
Rubber Tubing, .31 I.D.
14900-00 Tubing Clamp, .25-.63
45977-00 Inlet Power Harness 115V
45977-01 Inlet Power Harness 230V
45985-00 Door Fan Assy
45866-00 Relay Board Cover
45994-00 Blower Filter Assy 230V
45995-00 Blower Filter Bracket 230V
45859-00 Wiring Harness, T Sensor & Switch
Door Assembly
45862-06 Switch Assy
45862-03 Baffle Seal
45862-02 Lens Assy
45862-00 Electrical Enclosure Cover
45861-01 Water Deflector Baffle Assy
45861-03 PCBoard Enclosure Gasket
45861-00 Control Panel
45854-00 PC Board Assy
45854-03 PC Board Assy
45162-00 Soap Dispenser Mounting Bracket (2)
44981-00 Soap dispenser (110V/240V)
45123-00 Light Assy
45094-00 Bulb 115V
45094-01 Bulb 230V
45062-00 Latch Knob
45040-00 Hinge Assy LH
45040-01 Hinge Assy RH
45855-00 LCD Display
45075-00 Light Window
16474-02 Light Window Gasket (2)
45862-01 Door Window
16474-03 L/R Door Window Gasket (2)
16474-04 T/B Door Window Gasket (2)
45923-00 Control Label
45883-00 Door Harness, 115V/230V
45858-00 Flat IDC Control Cable
45929-08 Latch Mechanism
Lower Rack Assembly (SteamScrubber)
44277-08 Carton Assy
44254-00 Roller (8)
44457-00 Roller Clip (8)
44492-00 Basket Bumper (4)
45846-01 Lower Basket
Upper Rack Assembly (SteamScrubber)
44492-00 Basket Bumper (2)
14404-00 Wash Arm Pipe Plug (2)
45909-01 Distrib. Tube Spring
45810-02 Distrib. Tube Cap
45870-02 Distrib. Tube
45870-01 Distrib. Tube Bracket
45847-09 Water Inlet Adapter
45847-05 Upper Basket Latch
45847-01 Upper Basket
45712-02 Wash Arm Assy (Middle)
Lower Spindle Rack Assy (FlaskScrubber)
45918-00 Spindle, Short
45918-01 Spindle, Long
45847-08 Spindle Tool
44254-00 Roller
44457-00 Roller
Clip
44251-01 Manifold Plug
44492-00 Basket Bumper
45960-00 Small Spindle w/ Clip (10pk)
45846-01 Lower Basket
45847-09 Water Inlet Adapter
45852-00 Glassware Holder
45852-02 Glassware Holder Clip
45846-07 Tube Cap
45846-02 Lower Spindle Weldment
