65
Glassware Washer/Test Report
MODEL NUMBER VOLTS/HZ M.O. NUMBER SERIAL NUMBER INSP/TECH/ DATE QTY/OF
INSP/TESTS No. CONDITIONS AND REQUIREMENTS INST/LCC# RESULTS PASS
Set-Up
1 Connect tap and pure water.
2 Connect drain.
3 Connect electrical power. (230V, 50 Hz)
4 Connect current probe to power line.
5
6
7
8
Close detergent cup door
Connect computer via RS232
Connect test dispense bottles to the detergent & acid supply lines.
Set up washer control
A. Open door
B. Press and hold ▼ button- Simultaneously close and latch door.
C. Press ▼ button to select function. Press ◄ or ► to actuate
function.
1) Set Temp Units - °C
2) Set DI Pump to Enable- YES
3) Set Light - ON
4) Set Factory Reset – YES
D. Press RUN
Hi-Pot 1 1000V for 1 minute. Hi Pot Tester ____________
Temperature 1
Position thermocouple near temperature probe.
Test
2 Press and hold ◄ button - simultaneously close and latch door.
3 Display must agree with temperature meter ±2°C. Temperature Meter
Self Test 1 Open door
2 Press & hold ▲ button – Simultaneously close and latch door.
3 Press ▼ button to select function. Press ◄ or ► to actuate
function.
TAP WATER Visual
PURE WATER Visual
Continue in this mode until Float Switch shuts off water flow. Visual
Open door to check water level. Bottom of heater must be
