68
SECTION VI:
Wiring Schematics
Each unit comes with a built-in Wiring Schematic/Diagram. This
diagram can be found on the internal side of the door’s outer
skin panel. There is not one included in the User’s
Instructional Manual. For the purposes of Electrical
Troubleshooting, all three Wiring Schematics have been included
in this Service Manual.
A note on Electrical Troubleshooting
Due to the extensive nature of electrical troubleshooting, there will
not be any detailed instructions on how to perform step-by-step
electrical testing of systems.
The wiring schematics can aid you through this process of testing
specific parts of the circuit as dictated by the symptoms of a
problem. If at any point you require assistance or wish to get a
second opinion, feel free to contact Labconco’s Product Service
Department at 1(800)821-5525, at [email protected], or at
www.labconco.com.
