5
IND100131-22
Contents of package
Item Description Illustration
FS-CABLE EU
1 pcs of power cable European Type F “Schuko” to IEC.
Length 1.8m
Note: Included in package for models with AC input.
EUR TYPE F
IEC
80099
1 pcs of power cable US Type B plug to IEC.
Length 1.8m
Note: Included in package for models with AC input.
US TYPE B
IEC
FCE17-E2W2SS-2NO &
L17DPPK09JSU (cover)
1 pcs of DC Power Input housing with internal cable screw terminal.
Note: Included in package for models with DC input.
DVI-4
1 pcs of DVI > RGB/VGA adapter
DVI 12+5P Male to DSUB 15P Female
1P06025 (screw) &
16M06012150 (washer)
4 pcs of M6X25 pan screws.
Suitable for securing the display unit into a console cut-out. See illustration to the
right.
DO NOT USE THESE TO MOUNT BRACKETS ONTO THE UNIT.
Use the provided and dedicated screws for accessories (see next table below)
MEDIA STD01
Documentation and Driver DVD for factory installed components like mainboard,
IDE, network etc. It also includes the Touch Screen driver for units delivered with a
factory mounted touch screen.
Note: To use this DVD disc you will need an external USB CD/DVD drive or provide
means of getting contents copied over via USB memory stick/network to MMC unit.
Menu and Driver
browser for
Microsoft® Windows®
Recovery Image
(located on hidden partition on SSD)
Note: Only applicable for factory delivered units with SSD hardware.
Test Report
Item Description Illustration
4 pcs of M6X12 Unbraco bolts. These are included with mounting bracket, if ordered
(review technical drawings chapter).
Should only be used to secure the bracket onto display.
If you prefer your own bolts, make sure they do not exceed 12mm in length. Use any
longer is not possible due to mechanical limits.
Package may also include:
