31
IND100129-161
All specifications are subject to change without prior notice!
Specifications - JH 15T17 MMC-xxx-Axxx (LED version)
SPECIFICATIONS
Note: All specifi cations are subject to change without prior notice!
Please visit www.hatteland-display.com for the latest electronic version.
2/2
• Operating : Temperature -15 deg. C to +55 deg. C
Humidity up to 95%
• Storage : Temperature -20 deg. C to +60 deg. C
Humidity up to 95%
• IP-Rating : Protection (EN60529): IP66 front - IP20 rear
• 412.00 (W) x 345.00 (H) x 73.28 (D) mm
• 16.22" (W) x 13.58" (H) x 2.89" (D)
• Weight: 8 kg (approx)
On front bezel - Potmeter control (IP66) xxx-xxBx models:
• Power On/Off (push button)
• Brightness Control (rotary control)
• Mode Status Red/Green/Orange Illuminated LED-Ring Indicator
• Buzzer
Behind IP66 Rated hatch:
• 1 x USB Type A connector(s)
• JH 15TBR STD-B1 = Mounting Bracket
• JH 15TRO STD-A1 = Rotary Bracket
• JH 15TSV STD-A1 = Sun Visor
• JH 15VED STD-A1 = Vesa Bracket
• JH 15TAP STD-A1 = 15" Adapter Frame to 19" Rack
• JH 15TAP STD-B1 = 15" Adapter Frame to 17" CRT cut out
• JH 15TWC STD-A1= Water Cover
• JH C01MF A-A = USB Cable 1m, Type A to Chassis mount receptacle
• HT 00300 MSOS = OS options -> http://www.hatteland-display.com/os
*Please see user manual/datasheet for more information
Power Supply Options:
• 115&230VAC - 50/60Hz : Model JH 15T17 MMC-Axx-xxxx
• 24 VDC : Model JH 15T17 MMC-Dxx-xxxx
Power Consumption:
• Operating AC/DC : 100W (max)
: 60W (typ) at max backlight+high CPU (Core2) load
: 50W (typ) at max backlight+high CPU (Celeron) load
• Resistive* or Capacitive Touchscreen
• Optical Bonding* Technology
• Up to 4GB of memory
• Storage Device, SSD or HDD
*Note that all 15 inch with resistive touch screens can not be combined with bonding.
CPU #1 - Intel® Core™2 Duo L7400 - 1.5GHz, 4MB Cache, 667MHz FSB
CPU #2 - Intel® Celeron® M ULV 423 - 1.06GHz, 1MB Cache, 533MHz FSB
Note: CPU #1 needs additional fan inside MMC unit.
• Installed OS : None or Microsoft® Windows® Embedded
Enterprise (XP Professional Eng w/SP2c, 32bit)
See also Accessories (HT 00300 MSOS) options
• Storage : 1 x 40GB, 80GB, 120GB or 300GB SSD (SATA 2.5”)
: or 1 x 1TB HDD (SATA 2.5")
• Processor : See option table below
• Installed Memory : 2 x 1 GB 667MHz DDR2 Non-ECC CL5 DIMM
• System Chipset : Intel® 82945GME
• Graphics Chipset : Intel® 945GME Integrated
• BIOS : Award BIOS, supports ACPI
• Speaker : None
• Buzzer : Yes, 3500Hz
• Power Manager : ACPI
• Monitoring : Temperature, voltage and fan monitoring
• Resolution Range : From 640 x 480 up to 2048 x 1536 @ 85 Hz*
• RGB OUT Resolution : From 640 x 480 up to 1600 x 1200
* Native 1:1 resolution recommended is 1024 x 768 @ 60 Hz.
* If resolution is set above 1:1, desktop scrolling mode will be used.
Connector Rear Internal Front
Ethernet GBLan : 2 x RJ-45
Keyboard : 1 x PS/2
Mouse : 1 x PS/2
COM : 2 x DB9M (RS-232/422/485 opto-isolated)
LPT1 : 1 x DB25F (Bi-directional/ECP/EPP)
USB 2.0 Type A : 4 x USB 1 x USB
DVI/RGB OUT : 1 x 29P DVI-I or as RGB with adapter
(DDC on RGB as default)
Compact Flash : 1 x CF Socket (Type I/II)
If AC Power : Std IEC inlet
If DC Power : 1 x 2p D-SUB Connector (male) - Amphenol FCC17
• 1 x miniPCI (Require mod cation of terminal plate)
A P P R O V A L S & C E R T I F I C A T E S
Available Accessories:
Input/Output Connectors:
Environmental Considerations:
Power Specifications:
Physical Dimensions:
This product have been tested / type approved by the following classification societies:
IEC 60945 4th (EN 60945:2002) IACS E10 IP66 ClassNK - Nippon Kaiji Kyokai
GL - Germanischer Lloyd DNV - Det Norske Veritas ABS - American Bureau of Shipping
BV - Bureau Veritas LRS - Lloyd’s Register of Shipping EU RO MR - Mutual Recognition
Safety Considerations:
Even although the test conditions for bridge units provide for a maximum
operating temperature of 55°C, continuous operation of all electronic
components should, if possible, take place at ambient temperatures of only
25°C. This is a necessary prerequisite for long life and low service costs.
Compass Safe Distance: JH 15T17 MMC-Axx-Axxx Standard: 55cm Steering: 35cm
Compass Safe Distance: JH 15T17 MMC-Dxx-Axxx Standard: 115cm Steering: 75cm
Factory Mounted Options:
Processor Options:
User Controls:
Computer Specifications:
For a full overview of model typenumbers, please review the following link:
www.hatteland-display.com/pdflink/ind100780-2.php
Capabilities / Prepared for:
• Native Resolution : 1024 x 768
• Pixel Pitch (RGB) : 0.297 (H) x 0.297 (V) mm
• Response Time Standard : 8ms (typical), black to white
• Contrast Ratio Standard : 700:1 (typical)
• Light Intensity Standard : 400 cd/m² (typical)
• Viewable Angle Standard : +/- 80 deg. (Up/Down/Left/Right) (typical)
• Active Display Area : 304.1 (H) x 228.1 (V) mm
• Max Colors : 16.7 million
• High Quality TFT with LED Backlight Technology
• 15.0 inch viewable image size, Aspect Ratio 4:3
• TFT active-matrix liquid crystal panel
TFT Technology:
TFT Characteristics:
