8
Model UD-2A-EDID
4.2.2.4 Disable output boost:
Output boost can also be disabled for the output signal equalization over a
long cabling when desired.
Co m m a n d ........................................... R e sp o n se
ASCII d or D (Hex 64 or 44)...............Disable boost (1=DVI – 2=UTP)
ASCII 1 (or Hex 31) ................................................. DVI boost disabled
ASCII 2 (or Hex 32) .................................................UTP boost disabled
4.2.2.5 Read EDID Information:
Read EDID information from the currently selected EDID routing
selection
Co m m a n d ........................................... R e sp o n se
ASCII r or R (Hex 72 or 52)....................................................................
Reading EDID info from DVI-Local (or UTP-Remote) Device
Or
Reading EDID info from Emulate Default (or Emulate Learned) memory
Output is in a tabular format similar to below:
