GoDEX EZ6000Plus series - Manual (Page 7)

3
EZ-2000+/6000+ User ’s Manua
Model EZ6200 Plus EZ6300 Plus
Print Method Thermal Transfer / Direct Thermal
Resolution 203 dpi (8 dot/mm) 300 dpi (12 dot/mm)
Print Speed 6 IPS (150 mm/s) 4 IPS (102 mm/s)
Print Width 6.61” (168 mm)
Print Length
Min. 0.16” (4 mm)**
Max. 118” (3000 mm) Min. 0.16” (4 mm)**
Max. 54” (1371 mm)
Memory 4MB Flash (2MB for user storage) ; 16MB SDRAM
Sensor Type Adjustable reflective sensor and transmissive sensor, left aligned
Media
Types: Continuous form, gap labels, black mark sensing, and punched
hole; label length set by auto sensing or programming
Width (Tear): 2” (50.8 mm) Min. - 7” (178 mm) Max.
Width (Cutter): 6.5” (165 mm) Max.
Width (Heavy duty cutter): 6.8” (172 mm) Max.
Width (Label Dispenser / Rewind): 7” (178 mm) Max.
Thickness: 0.003” (0.06 mm) Min. - 0.01” (0.25 mm) Max.
Label roll diameter: Max. 8” (203.2 mm) with 3" (76.2 mm) core / Max. 6”
(152.4 mm) with 1.5" (38.1 mm) core
Core diameter: 1.5” (38.1 mm) - 3” (76.2 mm)
Ribbon
Types: Wax, wax/resin, resin
Length: 1471’ (450 m)
Width: 2.36” Min - 6.85” (60 mm - 174 mm) Max
Ribbon roll diameter.: 2.99“ (76 mm)
Core diameter: 1” (25.4 mm)
Auto ink inside and ink outside
Printer Language EZPL (Firmware upgradable)
Software
Label design software: QLabel-IV (for EZPL only)
Driver & DLL: Windows 2000, XP and Vista
Resident Fonts
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°
rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable
Download Fonts
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°
rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in
horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable
