8

3 Vertical Collector and Hydraulic Connection Arrangement

1

4

5

...

1

12

11

2

...

Diagram 3.1

15025

14915

6 and up to 12 max Collectors

THE HYDRAULIC FLOW MUST BE DIAGONAL

1-5 Collectors

THE HYDRAULIC FLOW CAN BE TOP AND BOTTOM OR DIAGONAL

Collector Panel

The recommended collector panel arrangements are shown

below.

Hydraulic Connections

It is recommended that the hydraulic connections should be

made as shown below.

1

4

5

...

TOP & BOTTOM

DIAGONAL

DIAGONAL

Vertical
