Glow-worm Clearly Solar - A-Frame User Manual
Page 18
18
Diagram 7.1
15045
Horizontal
1
4
5
...
1
9
10
...
6 and up to 10 max Collectors
THE HYDRAULIC FLOW MUST BE DIAGONAL
1-5 Collectors
THE HYDRAULIC FLOW CAN BE DIAGONAL OR TOP AND BOTTOM
Collector Panel
The recommended collector panel arrangements are shown
below.
Hydraulic Connections
It is recommended that the hydraulic connections should be
made as shown below.
7 Horizontal Collector and Hydraulic Connection Arrangement
