Using the Optional Power Meters and VFL
16 Power Meter and VFL
Measuring Power or Insertion Loss
To view and edit power or insertion loss measurements:
1. Select the Measurements tab. All your measurements are displayed in
the order they were performed.
2. Tap Rename to rename the fiber, tap Delete to remove the selected
value from the list, or Clear All to remove all measurements from the
list.
To change the fiber name (in the case of multiple
wavelengths, they are all changed at the same time)
Fiber name
To delete the selected row from the table (in
the case of multiple wavelengths, they are
all deleted at the same time)
Wavelength at which power or
insertion loss was measured
Insertion loss measurement (in dB) or power
measurement (in dBm)
Average power
or insertion loss
measured per
wavelength
