Mportant – EXFO Inline Power Meter User Manual
Page 19
Using the Optional Power Meters and VFL
Power Meter and VFL
15
Measuring Power or Insertion Loss
7. Tap Add to transfer the displayed values to the Measurements list. In
auto-switching mode, the measurements are added for all
wavelengths at once, using one line per wavelength.
Note: If you tap Add just after switching to another measurement unit, the
application will prompt you to save any unsaved measurements. You must
either save these measurements and close the file, or discard them
(see Clearing Measurements from the Display on page 19) before being
able to add values expressed in the new measurement unit.
8. Once your work is complete, tap Save.
I
MPORTANT
If you specify a name that already exists, the original file will be
overwritten and only the new file will be available.
