Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 7
6
3. Slide the hard disk in the direction of arrow , and then slide it in the direction of
arrow to remove it.
4. Remove the adhesive hard disk cover .
5. Reverse the process to install a new hard disk.
Figure 6 - 6
Hard Disk Assembly
Removal
Figure 6 - 7
Hard Disk Cover
Removal
4
5
5
4
6
6
