Upgrading The Computer
Wireless Keyboard & Mouse USB Transceiver 6 - 5
6
Wireless Keyboard & Mouse USB Transceiver
If your purchase includes an optional Wireless Keyboard & Mouse Kit you can use
the USB port located behind the rear top cover to house the USB transceiver.
1. Remove the rear cover (see “Removing the Rear Top Cover” on page 6 - 3 ).
2. Insert the USB transceiver into the USB port .
3. Replace the rear top cover and screws.

Dongle & USB Ports
A single USB dongle is pro-
vided with the keyboard,
mouse and TV Tuner. This
dongle acts as a transceiv-
er for the keyboard and
mouse, and as a RF trans-
ceiver for the TV Tuner.
This dongle may be insert-
ed into any of the USB
ports, however if you have
included the TV Tuner in
your purchase option it is
recommended that you do
not plug the dongle into the
USB port located behind
the rear top cover in order
to prevent any interference.
Figure 6 - 4
USB Port for
Wireless Keyboard
& Mouse Kit
1 2
2
1
2
