Quick Start Guide
1 - 10 System Map: Left View
1
System Map: Left View
Figure 1 - 6
Left View
1. Stand
2. Multi-in-1 Card
Reader
3. ExpressCard
Slot (see page
2
- 7 )
4. 1 * USB 3.0 Port
5. HDMI-in Port
6. Line-In Jack
7. S/PDIF-Out Jack

ExpressCard Slot
The ExpressCard Slot
accepts either Ex-
pressCard/34 or Ex-
pressCard/54 formats.
2 3
4
5
6
7
1

HDMI-In Port
Note that the HDMI-In Port supports video
and audio signals from attached HDMI
devices.
Multi-in-1 Card Reader
The card reader allows you to use the most
popular digital storage card formats:
MMC (MultiMedia Card) / RSMMC
SD (Secure Digital) / Mini SD / SDHC /
SDXC Compatible
MS (Memory Stick) / MS Pro / MS Duo
USB 3.0 Port
The USB 3.0 port is denoted by its blue col-
or; USB 2.0 ports are colored black. Note
that the USB 3.0 port requires a driver in-
stallation (see
“USB 3.0” on page 4 - 7 ),
does not support wake on USB and is not
operational under DOS.
