Connection Procedure

Disconnect power from the system.

Remove the terminal cover to gain access to the wiring.

Remove the terminal cover and display module to gain access to the configuration link settings.

Configure the jumper switches as shown below (i.e. J1, J2, J4, J5, J8 and J9 switched ON, all others OFF)
J1 J2 J3 J4 J5 J6 J7 J8 J9

Connect the wires from the detector head to connector on the input module observing the following:
Detector Head Label
4-20mA Loop
Channel 1
Pin Number
Channel 2
Pin Number
Channel 3
Pin Number
Channel 4
Pin Number
– 14 26 38 50
+ 15 27 39 51

Connect power to the system and ensure the detector head operates (text on LCD display, LED will flash once every six
seconds approximately).

Perform software configuration (refer to ‘LC Software Configuration and System Calibration Manual’).

Perform system calibration (refer to ‘LC Software Configuration and System Calibration Manual’).
