GSM-60 ENMET Corporation
1
1.0 Introduction
The GSM-60 is a sample draw monitoring instrument that measures and detects certain toxic hazards gases. The GSM-60 was
designed primarily for monitoring one area with a single sampling hose, either for an individual gas or multiple gases. The
instrument has one sampling pump and one flow sensor. The instrument is available with up to 4 internal sensors. Available
sensors include, but are not, limited to carbon monoxide (CO), carbon dioxide (CO
2
), Hydrocarbons (HC) and variations in the
oxygen (O
2
) content. The sensors can be used alone or up to four sensors can be used together. Some applications require
monitoring of more then one area. If two sampling hoses are connected to one GSM-60 the flow sensor can only detect a total
flow fault condition. For example, a pump failure or both sampling hoses being blocked. The system can not detect a flow
fault if only one of the two sampling hoses is blocked. Flowmeters should be installed in both sampling lines to provide a
visual indication of proper flow. In the instrument, a 24
V DC sampling pump pass air over each sensor and the resulting
electrical outputs are used to evaluate the air for the target gases.
The
GSM-60 is a highly adaptable instrument. Some adaptations require an addendum be added to the manual to facilitate use
of the instruments with these adaptations. If addendum is needed, see page(s) between sections replacement part numbers and
warranty.
Some features of the instruments are as follows:
continuous monitoring of the sample air alarm relay contacts available on terminals
continuous LCD display of gas and vapor concentrations a fault relay and visual fault alarm
menu driven operational and maintenance controls low air flow fault indication and display
menu driven calibration procedure alarm acknowledgement capability including audio defeat
audio and visual alarms indicate unsafe conditions mA outputs for each target gas
Hydrocarbons (HC) are limited to gases with an ionization potential of 10.6 eV or less. See Appendix B for a list of gases and
IPs.
N OTE : All specifications stated in this manual may change without notice.
1.1 Unpack
Unpack the GSM-60 and examine it for shipping damage. If such damage is observed, notify both ENMET customer service personnel and
the commercial carrier involved immediately.
Regarding Damaged Shipments
N OTE : It is your responsibility to follow these instructions. If they are not followed, the carrier will not honor
any claims for damage.
This shipment was carefully inspected, verified and properly packaged at our company and delivered to the carrier in good condition.
When it was picked up by the carrier at ENMET , it legally became your company’s property.
If your shipment arrives damaged:
•
Keep the items, packing material, and carton “As Is.” Within 5 days of receipt, notify the carrier’s local office and request
immediate inspection of the carton and the contents.
•
After the inspection and after you have received written acknowledgment of the damage from the carrier, contact ENMET Customer
Service for return authorization and further instructions. Have your Purchase Order and Sales Order numbers available.
ENMET either repairs or replaces damaged equipment and invoices the carrier to the extent of the liability coverage, usually $100.00.
Repair or replacement charges above that value are your company’s responsibility.
The shipping company may offer optional insurance coverage. ENMET only insures shipments with the shipping company when
asked to do so in writing by our customer. If you need your shipments insured, please forward a written request to ENMET
Customer Service.
Regarding Shortages
If there are any shortages or questions regarding this shipment, please notify ENMET Customer Service within 5 days of receipt at the
following address:
1.2 Check Order
Check, the contents of the shipment against the purchase order. Verify that the GSM-60 is received as ordered. If there are accessories on
the order, ascertain that they are present. Check the contents of calibration kits. Notify ENMET customer service personnel of any
discrepancy immediately.
1.3 Serial Numbers
Each GSM-60 is serialized. These numbers are on tags on the equipment and are on record in an ENMET database.
2.0 Instrument Features
2.1 Exterior Features
The exterior of the instrument is shown in Figure 1. The exterior features are as follows:
ENMET Corporation
680 Fairfield Court
Ann Arbor, MI 48108
734-761-1270 734-761-3220 Fax
