Terminator parts identification, Assemble the following components to the pc board – Elenco DataCom Tester Kit User Manual
Page 17
-16-
PARTS LIST - SECTION E
SEMICONDUCTORS
Qty
Symbol
Value
Description
Part #
r 4
D1-D4
1N4148
Diode
314148
MISCELLANEOUS
Qty
Symbol
Description
Part #
r 1
PC Board Terminator LD-100
510005
r 1
J2
F-Connector
590500
r 1
J1
Modular Jack RJ-45
621028
SECTION E
Terminator
PARTS IDENTIFICATION
F-Connector
Modular Jack
Diode
PC Board
ASSEMBLE THE FOLLOWING COMPONENTS TO THE PC BOARD
In all of the following steps the components must be installed on the top legend side of the PC board. The
board is turned to solder the component leads on the foil side.
D4 - 1N4148 Diode
D3 - 1N4148 Diode
D2 - 1N4148 Diode
D1 - 1N4148 Diode
(see Figure D)
Note: R1 is not used.
Modular Jack (RJ-45)
(see Figure L)
J2 - F-Connector
Note: The connector must be
soldered in straight.
(see Figure K)
IMPORTANT: Cut off the excess
leads after soldering the F-
Connector to the PC board.
