-13-
MOUNTING PC BOARD TO CASE
Insert the PC board into the case and then secure the PC board to the case with a washer and nut (see
Figure U).
Use the cable tie to secure the wires as shown in Figure T.
Turn the pot fully counter-clockwise and push on the knob in the position shown in Figure V.
Install the tray by pushing down on it until it is flush with the case (see Figure U).
Figure U
Tray
Washer
Nut
Figure V
Figure T
Cable Tie
