Elenco 100kHz Function Generator in Kit Form - Manual (Page 2)

PARTS LIST
If you are a student, and any parts are missing or damaged, please see instructor or bookstore.
If you purchased this kit from a distributor, catalog, etc., please contact ELENCO
® (address/phone/e-mail is at
the back of this manual) for additional assistance, if needed. DO NOT contact your place of purchase as they
will not be able to help you.
RESISTORS
Qty. Symbol Description Color Code Part #
r 1 R6 200Ω 5% ¼W red-black-brown-gold 132000
r 1 R1 620Ω 5% ¼W blue-red-brown-gold 136200
r 1 R5 3.9kΩ 5% ¼W orange-white-red-gold 143900
r 1 R7 8.2kΩ 5% ¼W gray-red-red-gold 148200
r 1 R8 10kΩ 5% ¼W brown-black-orange-gold 151000
r 1 R4 22kΩ 5% ¼W red-red-orange-gold 152200
r 1 R9 100kΩ 5% ¼W brown-black-yellow-gold 161000
r 1 R2 10kΩ Potentiometer 192531
r 1 R3 100kΩ Potentiometer 192612
CAPACITORS
Qty. Symbol Value Description Part #
r 1 C6 820pF (821) 10% Discap 228210
r 1 C5 .01µF (103) 10% Mylar 240119
r 1 C4 .1µF (104) 10% Mylar 251017
r 1 C3 1µF 50V Electrolytic (Lytic) 261047
r 3 C2, C7, C8 10µF 16V Electrolytic (Lytic) 271045
r 1 C1 100µF 16V Electrolytic (Lytic) 281044
r 1 C9 1,000µF 16V Electrolytic (Lytic) 291044
SEMICONDUCTORS
Qty. Symbol Value Description Part #
r 1 U1 XR-2206 Integrated circuit (IC) 332206
MISCELLANEOUS
-1-
Qty. Description Part #
r 1 PC board 511003
r 2 DPDT switch PC mount 541009
r 1 Switch rotary 2p6pos 542207
r 1 Battery snap 590098
r 1 Battery holder 590099
r 3 Knob 622009
r 1 Case top 623061
r 1 Case bottom 623062
r 1 Binding post black 625031
r 3 Nut binding post 625031HN
r 3 Lockwasher binding post 625031LW
r 2 Binding post yellow 625034
Qty. Description Part #
r 4 Screw 2.8 x 8mm 641102
r 3 Hex nut 7mm 644101
r 1 Hex switch nut 9 x 15mm 644102
r 2 Flat washer 8 x 14mm 645101
r 1 Flat washer 9mm 645103
r 4 Rubber foot 662015
r 1 16-pin IC socket 664016
r 1 Label top panel 721008
r 1” Double-sided tape 740020
r 9” Black wire 22ga. 814120
r 1 Lead-free solder 9LF99
