Elenco Rhinoceros Mini-Beest Kit User Manual
Page 17
1.
4.
2.
5.
3.
Insert the leg tubes into the lower triangles.
Insert all twelve leg tubes in the same way.
Set firmly the inside and outside connecting rods
on the lower triangle, and then attach the lower
triangle cover on it.
Set the inside and outside connecting rods to
the upper triangle cover and attach the upper
triangle on it.
This completes one leg. Make a total of
twelve of these units.
There are thirteen leg tubes.
Only the twelve of them are
used for assembly. One is for
spare.
Firmly push the leg
tube all the way to the
bottom.
Connecting rods need to be set so
that "the circle mark used to push out
the part from die" is located inside and
the smooth surface is located outside.
Cut lines are on both sides.
When the cut lines are not
apparent, gently stretch the leg
tube to the right and left.
Metal shaft is attached.
There is a notch
on the tip.
There is a protrusion
on the tip.
Leg tube
Attach the crankshafts to the right and left frames. Snap
them into place, taking care to ensure that they are
attached in the correct direction.
Lower triangle
Upper
triangle
Connecting rod
(outside)
Connecting rod
(inside)
Left frame
Crankshaft
Crankshaft
Right frame
Lower
triangle
Leg tube
Upper triangle cover
Assembling the Legs of
Mini Rhinoceros
Mounting the Crankshafts
on the Frames
Set the connecting rods
in the direction so that
its hole is located at the
upper side.
The two crankshafts are exactly the
same, but they are to be oriented in
opposite directions when attached as
they will be linked together at the
end. Confirm that you have connected
the two crankshafts together as shown
in the picture. Pay attention to the
positions of the front and back sides of
the left and right frames.
When attaching the connecting rods, make sure that they
are attached in the correct direction.
Lower triangle cover
Separate the leg tube at the cut lines.
IMPORTANT
Connecting rod (inside)
Connecting rod
(outside)
Connecting rod
(inside)
IMPORTANT
IMPORTANT
It's a good chance to know that a crankshaft is made of crank axes for
rotation (with frames attached), crank pins moving in a circular motion
(with rods attached) and crank arms to connect them together.
The hole is located
at the upper side.
17
