b. Open a W browser and enter the following URL: 192.168.1.222. Your SmartServer home
page opens.
c. Click the Login button. A login dialog appears. Enter ilon for both the User Name and the
Password and then click OK. The SmartServer 2.2 – Welcome Web page opens.
d. You can configure your SmartServer and begin using its embedded applications as described
in the SmartServer 2.2 User’s Guide.
Mounting the SmartServer
!
Caution
For commercial installations, the SmartServer must be mounted inside a suitable, safety-
agency approved enclosure that is mounted in a restricted access area. High-voltage
wiring must be performed only by a qualified service person.
The SmartServer mounts to a 35mm x 7.5mm or 35mm x 15mm DIN rail. The rear of the SmartServer
enclosure contains a spring-loaded DIN rail lock, which securely grabs the DIN rail on which the
enclosure is mounted. To release the enclosure from the DIN rail, insert a flathead screwdriver into the
DIN rail locking tab and gently pull the tab downwards and away from the enclosure. The following
figure displays the location of the DIN rail-locking tab. All units are in millimeters.
The following figure displays the dimensions of the SmartServer and the space required for the various
connections. All units are in millimeters.
SmartServer 2.2 Hardware Guide 3
