DICE Electronics DOU VW - Manual (Page 11)

11
Connection Diagram
*Do not connect the iPod dock cable under any circumstance to the SIRIUS module connector!
Improper connection can cause permanent damage to iPod/SIRIUS module.
IR receiver
(optional)
Silverline DUO module
(front)
Silverline DUO module
(back)
Update port
(USB to PC)
iPod dock cable*
iPod/iPhone
(not included)
Vehicle BUS
connector
SIRIUS SAT radio
(not included)
Note: works with
DUO-103-AVW only!
Auxiliary device
(not included)
AUX connector
(optional)
SIRIUS connector*
