MultiMerge2
User
Manual
5
Technical
Specifications
INPUTS
3 AES-3 PCM inputs for 5.1 Surround
1 AES-3 PCM input for 2.0 AUX Stereo
1 AES-3 PCM input for EAS/CAP
1 AES-3/AES-11 input for external AES sync
1 HD/SDI Input with option
OUTPUTS
3 AES-3 PCM outputs for 5.1 Surround
1 AES-3 PCM output for 2.0 AUX Stereo
1 HD/SDI Pass-through output with option
AUDIO INPUT & OUTPUT
INTERFACE
AES/EBU, 75 ohm, unbalanced BNC
HD-SDI input for SMPTE 259M, SMPTE 292M, SMPTE 424M, ITU-
R BT.656 and ITR-R BT.601 input with option
LOUDNESS MEASUREMENT
& CORRECTION
ITU-R BS.1770/1 Industry Standard Loudness Measurement
DTS Neural Loudness Measure
Leq (a), Leq(b), Leq(c) and Leq(m)
SAMPLE RATE 32 kHz to 96 kHz, 24-bit
LATENCY
38ms UpMix HD High Latency
0ms Lt/Rt DownMix
48ms DTS Neural Loudness Control
<6ms for Hardware Interface
GPIO
Opto-isolated DB-9 female connector
0-5VDC TTL
ETHERNET 10/100 Base-T for field software updates, logging and remote control
DIMENSIONS & WEIGHT
1 RU, 19” (482mm) W x 8” (203mm) L x 1.75” (44mm) H
7lbs. (3.2kg)
ENVIRONMENTAL Convection cooled. Operating: 0 to 60 degrees C
REGULATORY
North America: Designed to comply with FCC Class A, Part 15
Europe: LV Directive 73/23/EEC and EMC Directive 89/366/ECC,
CE Mark (EN55022 Class A, EN55024)
RoHS and WEEE compliant
POWER SUPPLY
Dual redundant
Auto-sensing 100-240V, 50-60Hz
EMI suppressed male IEC320 connector
OPTIONS
HD/SDI input for 8 de-embedded audio channels from SDI group 1
or 2
WARRANTY Three year, limited parts and labor
NOTES [1] Does not include added latency of any options
*Specifications are subject to change without notice to upgrade the performance of our products.
