3. Rodless Cylinder Load Vs. Velocity
Rodless Cylinder
Horizontal Applications
Bore Size
Average Velocity With-
out Overshoot
@ Maximum Payload
[in/sec]
Maximum Payload
[lbs.]
Average Velocity @
50% Maximum
Payload
[in/sec]
Average Velocity @ 25%
Maximum Payload
[in/sec]
USS-09X-L
6
84
16
27
UGS-09X-L
10
104
20
36
USS-17X-L
8
260
22
27
UGS-17X-L
7
260
21
30
Rodless
Vertical Applications
Bore Size
Average Velocity With-
out Overshoot
@ Maximum Payload
[in/sec]
Maximum Payload
[lbs.]
Average Velocity @
50% Maximum
Payload
[in/sec]
Average Velocity @ 25%
Maximum Payload
[in/sec]
USS-09X-L
24
12
26
28
UGS-09X-L
13
24
25
30
USS-17X-L
9
60
10
13
UGS-17X-L
10
48
17
22
