Dynex DX-E402 - Manual (Page 19)

Specifications 19
Note: After the above configuration takes effect, configure your router by typing
http://192.168.1.1:88 (your router's LAN IP address: Web Management Port) in
the address field of the Web browser.
4 Log in to your router, click the Forwarding on the left of your browser, then click
Virtual Servers. The Virtual Servers page opens.
5 Click Add New. The Add or Modify a Virtual Server page opens.
6 Enter 80 into the Service Port field, and your IP address in the IP Address field (for
example, 192.168.1.188 ).
7 Select Enable for Status, then click Save.
Specifications
General
Standards IEEE 802.3, 802.3u
Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports One 10/100M Auto-Negotiation WAN RJ45 port. Four 10/100M
Auto-Negotiation LAN RJ45 ports supporting Auto MDI/MDIX
Cabling Type 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 ohm STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 ohm STP (maximum 100m)
Power Supply 9V~ 0.8A
LEDs Power, System, Link/Act
Safety & Emissions FCC
Environmental and Physical
