MATRIX-1000™ QUICK GUIDE
6
STEP 4 – INSTALLING VISISET™ CONFIGURATION PROGRAM
VisiSet
™ is a Datalogic reader configuration tool providing several important advantages:
• Autolearning Wizard for new users;
• Defined configuration directly stored in the reader;
• Communication protocol independent from the physical interface allowing to consider the reader as a remote
object to be configured and monitored.
To install VisiSet™, turn on the PC that will be used for the configuration, running Windows 98, 2000/NT or
XP, then insert the VisiSet™ CD-ROM, wait for the CD to autorun and follow the installation procedure.
This configuration procedure assumes a laptop computer, running VisiSet™, is connected to the reader's auxiliary
port.
WIZARD FOR QUICK READER SETUP
After installing and running the VisiSet™ software program the following window:
Figure 7 - VisiSet™ Opening Window
Set the communication parameters from the "Options" menu. Then select "Connect", the following window
appears:
Figure 8 - VisiSet™ Main Window After Connection
