MATRIX-1000™ QUICK GUIDE
10
APPENDIX
READING FEATURES
READING FEATURES
Frame Rate
Up to 30 frames/sec. with VGA images
Readable
Codes per
Frame
Up to 100
Pitch
10° - 35°
Tilt
0° - 360°
Reading Distance
(3)
mm (in)
MODELS
Focus
Distance
mm (in)
Field of View
(1)
mm (in)
ppi
(2)
Typ. Linear
and Stacked
Code
Resolution
mm (mils)
Typ. 2D
Code
Resolution
mm (mils)
min.
max.
1021 HD
115 (4.53)
25
Ч 19
(0.98
Ч 0.75)
653 0.10
(4)
0.19 (7.5)
105 (4.13)
125 (4.92)
1031 SD
155 (6.10)
34
Ч 26
(1.34
Ч 1.02)
478 0.15
(6)
0.25 (10)
135 (5.31)
180 (7.08)
1041 LD
110 (4.33)
54 x 40
(2.13
× 1.57)
300 0.20
(8)
0.38 (15)
90 (3.45)
140 (5.51)
1051 MR
210 (8.26)
95
Ч 70
(3.74
Ч 2.75)
170 0.30
(12)
0.60 (24)
150 (5.90)
250 (9.84)
(1)
@ Focus Distance
(2)
Pixels per Inch @ Focus Distance
(3)
Measurement Conditions:
•
Test Chart: provided with the reader
•
Still code at the center of the FOV
•
Code Symbology: Data Matrix ECC 200
•
Code Resolution: Typ. 2D Code Resolution
•
Tilt Angle: 45°
•
Skew Angle: 15°
•
Image Processing Mode: Advanced Code Setting
Depending on the code resolution, symbology and number of characters in the code, the Reading Area can be
different from the FOV.
