MATRIX-1000™ QUICK GUIDE
11
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Supply Voltage
10 to 30 Vdc
Power Consumption 4 W max.; 2.5 W typical
Communication Interfaces
Main - RS485 half-duplex
Auxiliary - RS232 2400 to 115200 bit/s
2400 to 115200 bit/s
Input
External Trigger
Opto-coupled and polarity insensitive
Outputs
OUT3 Opto-coupled
OPTICAL FEATURES
Image Sensor Matrix CCD
Image Format VGA (640x480)
Lighting System LED array
Wavelength 630 ~ 670 nm
Max LED Output Power 0.7 mW to EN60825-1
LED Safety Class Class 1 to EN60825-1
USER INTERFACE
LED Indicators PWR, TRIG, READ, COM, F1, F2
Keypad Button Configurable via VisiSet™
SOFTWARE FEATURES
Readable Code Symbologies
1-D and stacked 2-D POSTAL
• PDF417 Standard and Micro PDF417
• Code 128 (EAN 128) • Data Matrix ECC 200
(Standard)
• Australia Post
• Royal Mail 4 State Customer
• Code 39 (Standard and Full ASCII)
• Interleaved 2 of 5 • QR Code
(Standard)
• Kix Code
• Japan Post
• Codabar • MAXICODE • PLANET
• Code 93 • Aztec Code • POSTNET, POSTNET (+BB)
• Pharmacode
• EAN-8/13 - UPC-A/E
(including Addon 2 and Addon 5)
• GS1 DataBar (RSS) Family
• Composite Symbologies
• Microglyph
(this symbology requires an
activation procedure – contact your
local Datalogic Automation
distributor for details)
• POSTNET + PLANET,
POSTNET (+BB) + PLANET
Operating Mode O NE S HOT , C ONTINUOUS , P HASE M ODE
Configuration Mode By means of VisiSet™ configuration software
Parameter Storage Permanent memory (Flash)
SYMBOL VERIFICATION
Standard Supported Symbologies
ISO/IEC 16022 Data Matrix ECC 200
ISO/IEC 18004 QR Code
MECHANICAL FEATURES
Dimensions 121 x 73 x 57 mm (4.76 x 2.87 x 2.24 in.)
Weight 330 g. (11.6 oz.)
Material Magnesium alloy
ENVIRONMENTAL FEATURES
Operating Temperature 0 to 40 °C (32 to 104 °F)
Storage Temperature -20 to 70 °C (-4 to 158 °F)
Max. Humidity 90% non condensing
Vibration Resistance IEC 68-2-6 test FC 14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz
2 g @ 70 to 200 Hz; 2 hours on each axis
Shock Resistance IEC 68-2-27 test EA 30 g; 11 ms; 3 shocks on each axis
Protection Class IP64 (sealed connectors required)
