MATRIX-1000™ QUICK GUIDE
13
PATENTS
This product is covered by one or more of the following patents:
U.S. patent: 6,512,218 B1; 6,616,039 B1
European patent: 999,514 B1; 1,014,292 B1.
SERVICES AND SUPPORT
Datalogic provides several services as well as technical support through its website. Log on to
www.automation.datalogic.com and click on the links indicated for further information including:
• PRODUCTS
Search through the links to arrive at your product page where you can download specific Manuals and
Software & Utilities including:
- VisiSet™ a utility program, which allows device configuration using a PC. It provides RS232 interface
configuration.
•
SERVICES & SUPPORT
- Datalogic Services - Warranty Extensions and Maintenance Agreements
- Authorised Repair Centres
• CONTACT US
E-mail form and listing of Datalogic Subsidiaries
COMPLIANCE
EMC COMPLIANCE
In order to meet the EMC requirements:
• connect reader chassis to the plant earth ground by means of a flat copper braid shorter than 100 mm;
• connect the main interface cable shield to pin 1 of the reader 25-pin connector;
• use two clip-on ferrite sleeves (type Stewart 28A2029-0A0) on the main interface cable near the reader
25-pin connector;
POWER SUPPLY
This product is intended to be installed by Qualified Personnel only.
This product is intended to be connected to a UL Listed Computer which supplies power directly to the reader or a
UL Listed Direct Plug-in Power Unit marked LPS or “Class 2”, rated 10 to 30 V, minimum 1 A.
CE COMPLIANCE
Warning: This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
WEEE COMPLIANCE
