GOT3126T-834 User’s Manual
Introduction 3
System Specification
 12.1 ” XGA (1024x768) LCD with LED backlight, 600nits(before touch)
 5-wire resistive touch
 Fanless Heat Dispensing Design
 IP65 aluminum front bezel
 3 keys OSD on front panel
 Disk drive housing:
 1 x 2.5 ” SATA drive
 Net Weight
 2.8 Kgs
 Dimension (Main Body Size)
 311.8 x 56.9 x 250.3 mm
 Operation Temperature
 -20℃ to 55℃
 Relative Humidity
 10% to 90% @ 40℃, Non-Condensing
 System Power input
 DC power input : 9~36VDC with phoenix power connector
NOTE: All specifications and images are subject to change without notice.
