Audio Lin In connector: CN15
CN15 Pin Assignment
Pin Description
1
LINE IN L
2
GND
5
LIN IN R
Power lamp connector: CN16
CN16 Pin Assignment
Pin Description
Pin
Description
1
Power (+5V)
2
GND
Power button connector: CN17
CN17 Pin Assignment
Pin Description
Pin
Description
1
Power Button
2
GND
