FDK172-834 User’s Manual
Hardware and Installation 15
2.6 HDD Installation
The FDK172-834 provides a convenient Hard Disk Drive (HDD) bracket for users to install 2.5 ”
SATA HDD. Please follow the steps:
Step 1 Refer section 2.1 to open the back cover.
Step 2
Unscrew 4 screws to take off the HDD bracket.
Step 3 Fix the HDD on bracket by 4 screws, and connect SATA cable as well as
power cable.
