FDK172-834
User’s Manual
8
Hardware and Installation
2.1
Open and close back cover
This section tells users how to open and close the back cover. Please follow the steps below.
Step 1
Unscrew eleven screws on the back cover. Please refer the photo of top side,
right side and left side.
Step 2
When users open the back cover, there is a cable connecting between a fan
and the motherboard.
