2.3.31.5 Serial Port Signals
Note that all serial port signals on EEV-EX03 connectors are logic level signals. External
transceiver devices are necessary for the conversion of the logic level signals to the desired
physical interface such as RS232, RS422, or RS485.
Signal
Signal Description
DTR1#, DTR2#
Active-low data terminal ready outputs for the serial port. Handshake output signal
notifies the modem that the UART is ready to establish a data communication link.
RI1#, RI2#
Active-low input is for the serial port. Handshake signals notify the UART when a
telephone ring signal is detected by the modem.
TXD1, TXD2
Transmitter serial data output from serial port.
RXD1, RXD2
Receiver serial data input.
CTS1#, CTS2#
Active-low input for serial ports. Handshake signals notify the UART when the
modem is ready to receive data.
RTS1#, RTS2#
Active-low output for serial port. Handshake signals notify the modem when the
UART is ready to transmit data.
DCD1#, DCD2#
Active-low input for serial port. Handshake signals notify the UART when a carrier
signal is detected by the modem.
DSR1#, DSR2#
This active-low input is for serial port. Handshake signals are use to notify the
UART that the modem is ready to establish the communication link.
2.3.31.6 VGA Signals
Signal
Signal Description
HSY
Horizontal Sync: This output supplies the horizontal synchronization pulse to the
CRT monitor.
VSY
Vertical Sync: This output supplies the vertical synchronization pulse to the CRT
monitor.
R, G, B
Red, green and blue analog video output signals for CRT monitors. These lines
should be terminated with 75 ohms to ground at the video connector.
DDCK, DDDA
These two pins can be used for a DDC interface between the graphics controller
chip and the CRT monitor.
