User ’s Manual
EQM-CDV User ’s Manual 41
Item Option Description
MRC Fast Boot
Disabled[Default]
Enabled
Enable or disable MRC fast boot
Max TOLUD
Dynamic[Default]
1GB
1.25 GB
1.5 GB
1.75 GB
2 GB
2.25 GB
2.5 GB
2.75 GB
3 GB
3.25 GB
Maximum Value of TOLUD.
Dynamic assignment would adjust
TOLUD automatically based on
largest MMIO length of installed
graphic controller.
3.6.3.1.2 Intel IGD Configuration
Item Option Description
VBIOS Version 1053/1059/1071[Default] Select the VBIOS version
IGFX - Boot Type
VBIOS Default[Default]
CRT
CRT + LVDS
CRT + HDMI (Twin)
LVDS
LVDS + CRT
HDMI
HDMI + LVDS
Select the Video Device which will
be activated during POST. This
has no effect if external graphics
present.
LCD Panel Type
VBIOS Default[Default]
640x480 LVDS
800x600 LVDS
1024x768 LVDS
1280x1024 LVDS
Select LCD panel used by Internal
Graphics Device by selecting the
appropriate setup item.
