Avalue EQM-CDV - Manual (Page 18)

EQM-CDV
18 EQM-CDV User ’s Manual
Signal PIN PIN Signal
LVDS_DATA1_N 105 106 NC
LVDS_DATA2_P 107 108 NC
LVDS_DATA2_N 109 110 NC
LVDS_VDDEN 111 112 LVDS_BKLTEN
LVDS_DATA3_P 113 114 NC
LVDS_DATA3_N 115 116 NC
GND 117 118 GND
LVDS_CLK_P 119 120 NC
LVDS_CLK_N 121 122 NC
LVDS_BKLTCTL 123 124 NC
LVDS_DDC_DATA 125 126 LVDS_CTRL_DATA
LVDS_DDC_CLK 127 128 LVDS_CTRL_CLK
NC 129 130 NC
HDMI_CLKP 131 132 NC
HDMI_CLKN 133 134 NC
GND 135 136 GND
HDMI_TXDP1 137 138 NC
HDMI_TXDN1 139 140 NC
GND 141 142 GND
HDMI_TXDP0 143 144 NC
HDMI_TXDN0 145 146 NC
GND 147 148 GND
HDMI_TXDP2 149 150 HDMI_DDC_SDA
HDMI_TXDN2 151 152 HDMI_DDC_SCL
HDMI_HPD_N 153 154 NC
PCIE_CLK_REF+ 155 156 PCIE_WAKE#
PCIE_CLK_REF- 157 158 PCIE_RST#
GND 159 160 GND
NC 161 162 NC
NC 163 164 NC
GND 165 166 GND
PET_P2 167 168 PER_P2
PET_N2 169 170 PER_N2
Signal PIN PIN Signal
UART_TX 171 172 UART_RTS
PET_P1 173 174 PER_P1
PET_N1 175 176 PER_N1
UART_RX 177 178 UART_CTS
PET_P0 179 180 PER_P0
PET_N0 181 182 PER_N0
GND 183 184 GND
LPC_AD0 185 186 LPC_AD1
LPC_AD2 187 188 LPC_AD3
LPC_CLK 189 190 LPC_LFRAME#
SERIRQ 191 192 LPC_LDRQ0#
+VRTC 193 194 SPKR
FAN_TACHOIN 195 196 FAN_PWMOUT
GND 197 198 GND
SPI_MOSI 199 200 SPI_CS#
SPI_MISO 201 202 NC
SPI_CLK 203 204 NC
+5V_STANDBY 205 206 +5V_STANDBY
NC 207 208 NC
NC 209 210 NC
+5V 211 212 +5V
+5V 213 214 +5V
+5V 215 216 +5V
+5V 217 218 +5V
+5V 219 220 +5V
+5V 221 222 +5V
+5V 223 224 +5V
+5V 225 226 +5V
+5V 227 228 +5V
+5V 229 230 +5V
