EQM-CDV
10 EQM-CDV User ’s Manual
1.4 System Specifications
System
CPU Onboard Intel CDV-M N2600 1.6GHz or N2800 1.86GHz CPU
BIOS AMI 16M-bit SPI BIOS
System Chipset Intel NM10 Express Chipset
I/O Chip N/A
System Memory Onboard DDR3 800/1066, up to 2GB DDR3 800/1066 SDRAM
SSD Optional On board 2GB NAND Flash up to 16GB
Watchdog Timer Reset: 1 sec.~65535 sec./min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring system temperature, voltage. Auto trotting control when CPU overheats
I/O
MIO 1 x SATA port to baseboard if support SSD ,else 2 x SATA ports to baseboard.
USB 7 x USB 2.0 ports to baseboard
IrDA N/A
Others LPC, SMBus, I2C,SDIO
External I/O Connector Qseven spec 2.0 connector for expansions
Display
Chipset Intel Cedarview integrated graphics
Resolution
HDMI mode: 1920 x 1200 @ 60Hz
LCD/Simultaneous mode : 1366 x 768 @ 60 Hz (CDV-M)
Multiple Display HDMI + LVDS to baseboard
LCD Interface Single channel 18-bit LVDS
TV-out N/A
Audio
Audio Interface HD audio I/F
Ethernet
LAN Chip 1 x Intel 82574L Gigabit Ethernet
Ethernet Interface 10/100/1000 Base-Tx Gigabit Ethernet Compatible
Mechanical &
Environmental
Power Requirement +5V
ACPI
Single power ATX Support S0, S3, S4, S5
ACPI 3.0 Compliant
Power Type Qseven power spec
Operating Temp. 0 to 60

C
Storage Temp. -40 to 75
