ENX-CDD User ’s Manual
8 ENX-CDD User ’s Manual
1 x 5-pin Header for Inverter
1 x CIR for remote control
1 x Powr on/off with Power LED button
USB 3 x USB 2.0/1.1 Type A connectors , 1 x 4-pin Header for USB
Parallel Port NA
PS2 KB/MS 1 x 6-pin Header for 1 x PS2 keyboard / PS2 Mouse
DIO 1 x 8-pin Header for 4-bit General Purpose I/O for DI and DO
Display
Chipset Integrated Intel® Graphics Media Accelerator
Resolution
VGA /HDMI Mode: 1920 x 1200
Singel-channel 18/24 bit LVDS 1440 x 900 for D2550 Processor
Singel-channel 18 bit LVDS 1366 x 768 for N2800 Processor
Dual Display Yes , LVDS+VGA, VGA+HDMI, HDMI+LVDS
Audio
Audio Codec Realtek ALC661 HD Audio Decoding controller
Audio Interface Mic-in , Line out
Audio Amplifier Realtek ALC105 3W Stereo Class-D Audio Amplifier(1 x 4-pin Header)
Ethernet
LAN Chip 1 x Realtek RT8111E PCIe Gigabit Ethernet
Ethernet Interface 10 /100 /1000 Base-Tx Gigabit Ethernet
SIM card
SIM card 1 x SIM Card socket
SD card socket
Realtek RTS5138 USB card reader controller support SD/SDHC card
Mechanical &
Environmental
Power Type 12V DC in
Operating Temp. 0 ~ 60°C (32 ~ 140°F)
Storge Temp -40 ~ 75°C (-40 ~ 167°F)
Operating
Humidity
0 ~ 90% Relative Humidity, Non-condensing
Size (L x W) 4.72” x 4.72” (120mm x 120mm)
Weight 0.88lbs (0.4kg)
Others
Ordering Information: ENX-CDD-N2800-A1R or ENX-CDD-D2550-A1R
Nano ITX Motherboard
Intel® Atom ™ CedarView D2550 or N2800 Processor with NM10 Chipset and
VGA ,LVDS, HDMI, Line in,Mic in,1GbE, 1 Mini PCIe,1 SATA,1 COM,3 USB, 1 PS2
KB,1 PS2 MS, 1 SD Card socket, 1 SIM card socket ,6 bits GPIO,3W Amplifier,DC
in ,w/SATA AUX board and cable,VGA cable x1,COM poart cable x1,CD driver
