ENX-CDD User ’s Manual
ENX-CDD User ’s Manual 15
J3 Speaker connector 4 x 1 wafer, pitch 1.25 mm
J4 SIM card holder
JCOM1 Serial port 1 connector 5 x 2 header, pitch 2.00 mm
PWBT1 Power Button
JGPIO1 General Purpose I/O 4 x 2 header, pitch 2.54 mm
LPC Low Pin Count 5 x 2 header, pitch 2.00 mm
LVDS1 LVDS connector 15 x 2 wafer, pitch 1.00 mm
SATACON2 SATA AUX Board 12 x 1 wafer, pitch 1.00 mm
JUSB1 USB connector 4 x 1 wafer, pitch 1.25 mm
F_MIC1 Mic-in
F_OUT1 Line out
RJ1 LAN port
IR1 CIR connector
LED1 HDD LED
PJ1 DC-In
JKB_MS1 Keyboard & mouse connector 3 x 2 wafer, pitch 2.54 mm
F_USB1 USB connector1
F_USB2 USB connector2
F_USB3 USB connector3
INCN1 LCD Inverter connector 5 x 1 header, pitch 2.54 mm
SFAN1 System Fan connector 4 x 1 wafer, pitch 2.54 mm
JVGA1 VGA connector 5 x 2 header, pitch 2.54 mm
MPCIE1 Mini-PCI-e socket
DIMM1 DDR3 SODIMM socket
