ECM-BYT2 User’s Manual
ECM-BYT2 User ’s Manual 55
Item Option Description
OS Selection
Windows 8.X[Default]
Android
Windows 7
Please select the corresponding type of Windows for
OS installation.
Please change the item of OS selection to Windows 7
if you intend to install Windows 7 OS;
Please change the item of OS selection to Windows
8.X if you intend to install Windows 8 OS.
XHCI Mode
Enabled[Default],
Disabled
Mode of operation of xHCI controller.
3.6.3.2.3 PCI Express Configuration
Item Option Description
PCI Express Port 0/1/2/3
Enabled[Default],
Disabled
Enable or Disable the PCI Express Port
0/1/2/3 in the Chipset.
Speed
Auto[Default]
Gen 2
Gen 1
Configure PCIe Port Speed.
