ECM-BYT2 User’s Manual
ECM-BYT2 User ’s Manual 39
Enable Hibernation
Disabled
Enabled[Default],
Enables or Disables System ability to
Hibernate (OS/S4 Sleep State). This
option may be not effective with some
OS.
ACPI Sleep State
Suspend Disabled,
S3 (Suspend to RAM) [Default]
Select the highest ACPI sleep state the
system will enter when the SUSPEND
button is pressed.
ErP Function
Disabled[Default],
Enabled
ErP Function (Deep S5).
PWR-On After PWR-Fail
Off[Default]
On
Last state
AC loss resume.
Watch Dog
Disabled[Default],
30 sec
40 sec
50 sec
1 min
2 min
10 min
30 min
Select WatchDog.
3.6.2.2 IT8528 Super IO Configuration
You can use this item to set up or change the IT8528 Super IO configuration for serial ports.
Please refer to 3.6.2.2.1 and 3.6.2.2.2 for more information.
Item Description
Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA).
Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB).
