4.0 Assembly Steps – Uninstall Your Own ProV3
Step 1.
Disassembly the Inner Circle Assembly from your
ProV3 Camera Mount by moving 4pcs Alu Roll
Bearing shaft 39mm. Step 2.
Disassembly the whole Outer Frame Assembly
and keep all the screws and metal rods for the
later installation of the Upgrade Pack. Recognize
the installation direction of each parts and
frames. You may take a photo for later use.
Step 3.
Disassembly the Cam Stand Assembly and the
Tilt Servo from the Inner Circle Assembly. Keep
all the parts and screws for later installation of
Upgrade Pack. Step 4.
Disassembly the Fiber Tilt Servo Gear from the
Tilt and Pan Servo Horns.
